OWON SDS1052 Digital Storage Oscilloscope 50 MHz, 2-Channel, 500 MS/S


     OWON SDS1052 Digital Storage Oscilloscope The Owon SDS1052 Digital Storage Oscilloscope features 2 channels, up to 500MS/s real-time sample rates, maximum 50MHz bandwidth. The SDS1052 offers a 7-inch color LCD screen with 800x600 resolution. The SDS1052 has a ultra-thin body at only 70mm deep for portability, and it offers a 10K record length per channel of memory. Super Economical Type Digital Oscilloscope
Ultra-thin body 7 inch high resolution LCD SCPI, and LabVIEW supported



  • Digital Oscilloscope
  • Ultra-thin body
  • 7 inch high resolution LCD
  • SCPI, and LabVIEW supported
  • Bandwidth : 50MHz
  • Sample Rate : 500MS/s
  • Channel : 2
  • Display : 7" color LCD, 800 x 480 pixels
  • Input Impedance : 1MOhm +/- 2%, in parallel with 20pF+/-5pF
  • Channel Isolation : 50Hz : 100 : 1, 10MHz : 40 : 1
  • Max Input Voltage : 400V (PK - PK) (DC+AC, PK - PK)
  • DC Gain Accuracy : +/-3%
  • Record Length : 10K
  • DC Accuracy (average) : Average>=16?+/-(3% reading + 0.05 div) for V
  • Probe Attenuation Factor : 1X, 10X, 100X, 1000X
  • LF Respond (AC, -3dB) : >=10Hz (at input, AC coupling, -3dB)
  • Sample Rate / Relay Time Accuracy : +/-100ppm
  • Interpolation : sin (x) / x
  • Interval (T) Accuracy (full bandwidth) : Single : +/-(1 interval time + 100ppm x
  • reading + 0.6ns), Average>16 : +/-(1 interval time + 100ppm x reading + 0.4ns)
  • Input Coupling : DC, AC , and GND
  • Vertical Resolution (A/D) : 8 bits (2 channels simultaneously)
  • Vertical Sensitivity : 5mV/div - 5V/div (at input)
  • Trigger Type : Edge, Video
  • Trigger Mode : Auto, Normal, and Single
  • Trigger Level : +/-5 divisions from screen center Line / Field Frequency (video) : NTSC, PAL and SECAM standard Cursor Measurement : V, and T between cursors Waveform Math : +, -, x, ÷, invert, FFT Waveform Storage : 16 waveforms Communication Interface : USB host, USB device Frequency Counter : available Power Supply : 100V - 240V AC, 50/60Hz, CAT II Power Consumption : <15W Fuse : 2A, T class, 250V Dimension (W x H x D) : 301 x 152 x 70 mm Device Weight : 1.10 kg Includes: Power





Model SDS1052
Bandwidth 50MHz
Sample Rate 100MS/s
Horizontal Scale (s/div) 5ns/div - 1000s/div, step by 1 - 2 - 5
Channel 2
Display 7" color LCD, 800 x 480 pixels
Input Coupling DC, AC , and GND
Vertical Resolution (A/D) 8 bits (2 channels simultaneously)
Vertical Sensitivity 5mV/div - 5V/div (at input)
Trigger Type Edge, Video
Trigger Mode Auto, Normal, and Single
Waveform Math +, -, x, ÷, invert, FFT
Fuse 2A, T class, 250V
Dimension (W x H x D) 301 x 152 x 70 mm
Device Weight 1.10 kg



Paket İçeriği:

  • 1 Adet OWON SDS1052
  • 2 Adet Osiloskop Prob
  • 1 Adet Güç Kablosu
  • 1 Adet Data Cd
  • 1 Adet Usb Kablo
  • 1 Adet İngilizce Manual
