XL6005E1 Constant Current Driver


XL6005E1 60V 4A Anahtarlamalı Voltaj Yükseltici Sabit Akım Led Sürücü Entegresi


General Description
     The XL6005 regulator is fixed frequency PWM Boost (step-up) LED constant current driver, capable of driving Series 1W/3W/5W LED units with excellent line and load regulation. The regulator is simple to use because it includes internal frequency compensation and a fixed-frequency oscillator so that it requires a minimum number of
external components to work.

     The XL6005 could directly drive 11 Series 1W LED units at VIN>=12V .

     The PWM control circuit is able to adjust the duty ratio linearly from 0 to 90%. An enable function, an over current protection function is built inside. An internal compensation block is built in to minimize external component count.



  •  Wide 3.6V to 32V Input Voltage Range
  •  0.22V FB adjustable LED drive current
  •  Directly drive 11 Series 1W LED at VIN>=12V
  •  Fixed 180KHz Switching Frequency
  •  Max. 4A Switching Current Capability
  •  Up to 94% efficiency
  •  Excellent line and load regulation
  •  EN PIN TTL shutdown capability & With PWM Dimming Function
  •  Internal Optimize Power MOSFET
  •  Built in Soft-Start Function
  •  Built in Frequency Compensation
  •  Built in Thermal Shutdown Function
  •  Built in Current Limit Function
  •  Available in TO252-5L package



  •   LED Lighting
  •   Boost constant current driver
  •   Monitor LED Backlighting
  •   7’ to 15’ LCD Panels


Write a review

Note: HTML is not translated!
    Bad           Good


XL6005E1 Constant Current Driver

  • Brand: OEM
  • Product Code: XL6005E1
  • Availability: In Stock
  • Fiyat : 26.00TL
  • KDV Dahil : 31.20TL

Tags: XL6005E1, 60V, 4A, Anahtarlamalı, Voltaj Yükseltici, Sabit Akım, Led Sürücü Entegresi, Boost
