18650 Battery Holder 1 Slot

18650 Battery Holder 1 Slot

Lithium Battery Compartment Red Black Spring Contact Robot Powerbank Flashlight Sensor Toy Speaker

     The 18650 battery holder 1 slot is a black plastic single battery holder for one 3.7V 18650 lithium ion (Li-ion) battery. The metal contacts and the spring at both ends hold the battery firmly; thanks to the attached red (+) and black (-) wires, the connection to the circuit is made without soldering to the battery. With its open top design the battery is easily inserted and removed.

     Since it is a single holder, the output voltage is the voltage of one battery: nominal 3.7V, 4.2V with a fully charged battery. There is a spring metal contact on the negative side and a metal contact plate on the positive side. The 13cm - 15cm wires connect directly to a charging module, a protection board or a boost (step-up) module; the battery can be charged without taking it out of the holder. The ABS body is fixed inside the device with a screw through the hole in the base or with double sided tape.

     With its 75mm x 21mm x 20mm size and about 10gr weight, it fits into small boxes. Several holders can be connected in series or parallel with their wires to get higher voltage or capacity. The holder is delivered without battery.


Features:

• Product type:  Single 18650 battery holder with wires (battery case)
• Model: Battery Box 1
• Battery type: 1 piece 18650 lithium ion (Li-ion) battery
• Output voltage: battery voltage; nominal 3.7V, 4.2V with a fully charged battery
• Connection: 2 wires; red positive (+), black negative (-)
• Wire gauge: 24AWG (seller listings)
• Contacts: spring metal contact on the negative side, metal contact plate on the positive side
• Design: open top; the battery is easily inserted and removed
• Series / parallel use: several holders can be connected in series or parallel with their wires (batteries connected in parallel must be at the same voltage)
• Fixing: can be fixed with a screw through the hole in the base or with double sided tape
• Compatible modules: TP4056 charging module, BMS protection board, step-up boost module
• Ease of use: solderless battery connection, easy to carry
• Material: ABS plastic body, metal contacts
• Color: Black
• Wire length: 13cm - 15cm
• Dimensions: 75mm x 21mm x 20mm
• Weight: about 10gr

Usage information:

•  Insert the battery with its positive (+) end on the flat metal plate and its negative (-) end on the spring.
•  Connect the red wire to the positive (+) and the black wire to the negative (-) input of the circuit; check the polarity with a multimeter before connecting.
•  To charge the battery in the holder, connect the wires to a lithium charging module (e.g. TP4056); with an unprotected battery use the TP4056 version with protection circuit (DW01) or a separate BMS board.

Areas of use:

•  Arduino and ESP32 portable projects
•  Robot and robot car power supply
•  Powerbank and charging circuit projects
•  Flashlight and LED lamp
•  Wireless sensor and IoT nodes
•  Toy and model
•  Bluetooth speaker and audio projects
•  Education and STEM projects
•  Backup power and test setups

Precautions:

•  The holder is delivered without battery; the 18650 battery is not included in the package.
•  It is only for 18650 lithium ion batteries; long protected 18650 batteries (about 68mm - 70mm) may not fit in the holder.
•  A lithium battery gets very hot in a short circuit and can be dangerous; do not let the wire ends touch each other, use an unprotected battery with a BMS protection board.
•  Do not insert the battery reversed; reverse polarity damages the connected circuit.

Package contents:

•  1 Piece 18650 Battery Holder 1 Slot ( Without battery )
•  1 Piece red and black wire ( Assembled )

Note: The 18650 battery is not included in the package. Images are representative; the holder is delivered without battery.
