MR60 Connector Female Male Pair

     MR60 are connection connectors made of metal material with low resistance and a high current carrying capacity of up to 60A. It comes as a female male pair. It is suitable for 3-wire connections. They fit tightly into each other, providing a secure connection. The electrical connection is made without any problems. It has a physical plastic housing design that prevents reverse connection. It is suitable for use with your high current capacity Lipo batteries.

     The plastic material is resistant to the heat caused by high current. These connectors can be used in various extension, adapter and battery connections. They can be used in Lipo batteries, RC vehicles, robots and high amperage connections. You can use them with brushless motors that draw high current.

Features:

• MR60 connector
• Female male pair
• Protection caps
• Current: 40A  /  60A 1 min   (We recommend use at the 30A level.)
• Suitable for 3 Pin connection
• Angle: 180 Degrees
• Physical design that prevents short circuit and reverse connection.
• Semi-open end provides ease of soldering.
• Used for high current connections
• 3.5mm bullet type socket structure
• Cable Thickness: 12Awg  Maximum
• Internal resistance: 0.8mohm
• Quality plastic
• Gold plated brass
• Mechanical life: 500 mating cycles
• Operating temperature: -20C  /  120C
• Color: Yellow / Gold
• Weight: 9gr ( Pair )

Package contents:

•    1 Piece MR60 Male Socket
•    1 Piece MR60 Female Socket
•    2 Pieces Plastic Protection caps
