40A Brushless ESC

40A Esc Brushless Motor Speed Control Board

Drone Airplane Rc Fpv Toys Quadcopter Helicopter Brushless

     It is compatible with Lipo and NiMH batteries. Timing settings can be changed for different brushless motors. It has protections such as low voltage cutoff protection, over temperature protection, over throttle protection, throttle signal loss protection.

Features:

• Current: 40A
• Burst current (>10s): 55A
• Output capacity: Continuous current 40A, short term current 55A (not more than 10 seconds )
• BEC capacity: 4 Servo
• Battery type:  Lipo  / NiMH
• Battery cell count:  Lipo 2S / 4S
• Highly compatible with disk type motors.
• Bec mode: Linear
• BEC output: 5V / 3A
• Throttle calibration function support
• User programmable.
• Timing can be changed for different brushless motors.
• Maximum speed: 210,000rpm for 2 pole motor
• 7000rpm for 6 pole motor
• 35,000rpm for 12 pole motor
• Low voltage protection
• High temperature protection
• Throttle signal loss protection
• Color:  Black
• Operating temperature:  -10C  /  85C
• Dimensions:  8mm x 25mm x 68mm
• Weight:   30gr

Package Contents:

• 1 x 40A Brushless ESC
